Although good, the membrane switches can work most of the time, but still miss some notes. Again, I haven’t tried this approach, but like the pin-prick approach, the cost is nothing. Like this well documented instructions here ( Instructables). Another potential fix is to move the circuit board closer to the frets by placing duct tape on the ‘bottom’ of the printed circuit board (remember those spacers at the top of Figure 1?). Solutions include disassembly and cleaning the circuit board with a pink pencil eraser to remove any ‘stuff’ that may interfere with good conduction between the circuit board and the silicon membrane switch. Sometimes one (or more) fret buttons will begin to act-up, or stop working entirely. I haven’t tried it, but the cost to experiment is pretty low!īad fret. This has the effect of ‘weakening’ the silicon around each switch, allegedly providing for an easier ‘press’.
Guitar hero world tour pc mods how to#
There are many websites that show how to make the fret buttons ‘easier’ or ‘softer’ to push by strategically poking holes with a sewing needle around the perimeter of each switch, like this guy ( YouTube Video). Some players prefer the feel of a real switch over the feel of the silicone membrane. There are a couple of reasons why a player would want to make a change to ‘mechanical’ fret buttons.įeel. Why would you want to make the change to mechanical fret buttons? Inexpensive, and easy to mass produce and assemble in huge numbers. A circuit board, a silicon membrane switch and a fret button. These buttons just ‘sit’ in their holes in the guitar neck. When those two black dots meet the ‘zig-zag’ conductive lines printed on the circuit board, the circuit is completed and the electronics can tell which button is pressed.įigure 3 shows the silicone switch membrane was removed (and flipped over) revealing the colored fret buttons. There are five pairs of black, conductive circles that normally ‘float’ above the printed circuit board until you press the fret down with your finger. The clear/white silicon switch membrane can be seen, still in place, above the fret buttons. The two screws have been removed in figure 2, and the printed circuit board has been flipped-over to expose the ‘top’ (the business end). See that row of round cylinders sticking up? Those rest against the printed circuit board to prevent it from flexing while you are fingering the frets. Take a look toward the top of figure 1, which is the inside of the back of the guitar neck.
The ‘bottom’ of the printed circuit board is now visible, held in place with two screws, one at each end, and a ribbon cable that attaches the board to a connector at the guitar-end of the neck. For this guitar (World Tour), there are 8-10 T-10 torx screws holding it together. In figure 1, the back of the guitar neck has been removed. To see the way the fret buttons ship from the factory, we need to open up the neck of the guitar. What do the existing fret buttons look like? There are the bare minimum of moving parts and zero alignment/assembly issues. This approach of using a flexible membrane and conductive pads is a super inexpensive method of making thousands-and-thousands (millions even?) of products that work well and are easily mass produced. When a fret is pressed down, the membrane deforms, allowing the pads on the membrane to contact the mating pads on the printed circuit board, and the electronics are able to register the keypress. This all sits on top of a small printed circuit board that has matching conductive traces that align with the conductive pads on the silicon membrane. The membrane contains two conductive electrical pads. On a standard Guitar Hero type guitar, the fret buttons (red, green, yellow, blue, orange) sit above a silicon membrane. Guitar Hero Mechanical Fret Button Upgrades What’s the deal with the existing fret buttons?
